Ethernet and MII management
The following figure provides the data and command output timing diagram.
t T1588CLKOUT
t T1588CLKOUTH
FEC_1588_CLK_OUT
t T1588OV
FEC_1588_PULSE_OUT
FEC_1588_TRIG_OUT
Note: The output delay is count starting rising edge if t T1588CLKOUT is non-inverting. Otherwise, it is
count starting falling edge.
Figure 18. IEEE1588 Output AC Timing
The following figure provides the data and command input timing diagram.
t T1588CLK
t T1588CLKH
FEC_1588_CLK
FEC_1588_TRIG_IN
t T1588TRIGH
Figure 19. IEEE1588 Input AC Timing
MPC8309 PowerQUICC II Pro Integrated Communications Processor Family Hardware Specifications, Rev. 3
30
Freescale Semiconductor
